Electrical Characteristics
Item | Specification |
Characteristicimpedance（Ω） | 50±2 |
Frequencyrange（GHz） | 0~3 |
VSWR | ≤1.10 |
Contactresistance（mΩ） | Centercontact≤1,outercontact≤0.25 |
Dielectricresistance（MΩ） | ≥5000 |
PIM（dBc） | 155 |
MechanicalCharacteristics
Item | Specification |
Durability（cycles） | Matingcycles≥500 |
EnvironmentalCharacteristics
Item | Specification |
Temperaturerange（℃） | -40~+85 |
ThermalShockTestMethod | IEC60068-2-27/GB/T2423.5 |
VibrationTestMethod | IEC60068-2-6/GB/T2423.10 |
SaltMistTestMethod | IEC60068-2-11/GB/ T2423.17(48H, Neutral) |
