48 front 3.5" HDD (compatible with 2.5" HDD/SSD), 2 internal 2.5" HDD/SSD, 12 rear 3.5" HDD (compatible with 2.5" HDD/SSD),
Cooling fan
Standard 6 12038 ball bearing fans, high wind pressure, high air volume, with hot plug and shock absorption function
HDD extraction box
The hard disk extraction box adopts anti-EMI design, with light guide column, can indicate the working status of the hard disk, slide rail design, smooth extraction, optional drawer box for screw-free installation of hard disk
HDD backplane
Standard 12Gb expansion backplane, with fan PWM intelligent speed regulation, hard disk time-sharing start, SGPIO, cold storage, over-temperature alarm, power supply short circuit protection, support SATA/SAS/NVME and other functions, optional 6Gb expansion backplane
Suitable for motherboard
Maximum support 13.68"*13 (EE-ATX) and below motherboard size
System control
Power LED*1, Reset*1, Power SW*1, HDD LED*1, NIC LED*2*1, UID LED*1, UID SW*1, OH/FAN Fail LED*1, Power Fail LED*1
