RX24F53 Switch
TexAi
1. Basic | ||
Product Name | RX24F53 | |
Product Positioning | Data Center TOR access, Enterprise / Metro / HCI (Hyper-Converged Infrastructure) network access or aggregation | |
Switching Method | Store and Forwarding / Cut Through | |
Packets Buffer | 36MB | |
CPU Model | Dual core, ARM A53 | |
Flash | 8GB | |
Memory | 2GB | |
Hardware Configuration | Main Board Spec | 24 x 40GE QSFP+ Ports |
Uplink Network Sub Card | Not Support | |
Console Type | 1 RJ-45 Console port located at the left side of front panel | |
Outband Eth Management Port | 1 RJ-45 out-of-band management port located at the left side of front panel | |
Inband Eth Management Port | Support | |
USB Ports | 1 Type-A USB port located at the left side of front panel | |
2. Performance Spec | ||
Switching Capacity | Switching Capability | 1.92 Tbps |
Throughput | 1428.48 Mpps | |
Latency | 700 ns | |
3. Hardware and Software Description | ||
Hardware Architecure | Standard 1U 19'' rack mountable | |
Software Upgrade Method | TFTP/FTP | |
Service interruption time when reboot system for software update | Less Than 120s | |
4. The Power Supply and Power Requirements | ||
Type of Power Supply | AC | Support |
DC | Support | |
Power Supply Range | AC | Operating Voltage: 100 ~ 240V; 50/60Hz Maximum Voltage: 90 ~ 264V; 47~63Hz |
DC | Maximum Voltage: -40 ~ -72V | |
HVDC | Maximum Voltage: 180 ~ 300V | |
Double Power Input | Support | |
Power Supply Module Pluggable | Support | |
Typical Power Draw | 112W | |
Max Power Draw | 171W | |
PoE Power Budget | ||
5. Overcurrent and overvoltage protection | ||
Overcurrent/Overvoltage Protection | Support | |
Surge Protection Level | 4KV | |
6. Others | ||
Hardware Size (H×W×D) in. | 4.4 x 44.2 x 47.1 cm (1.7 x 17.4 x 18.5 in.) | |
Weight (kg) | 9.00KG | |
(Include Two PSU) | ||
Cooling Mode | Fan Cooling | |
Airflow Option | Front-to-Rear Airflow | |
Quantity of Fans | 4 | |
Fan Module Pluggable | Support | |
Fan Module Intelligent Speed Control | Support | |
Operating Temperature Range | 0ºC ~ 45ºC | |
MTBF(Hour) | >70080 | |
MTBF(Year) | >8.0 | |
The RX24F53 Switch, a product of TexAi, is a high-performance 24 x 40GE QSFP+ Ports switch. It is positioned as a key device for Data Center TOR access, as well as network access or aggregation in Enterprise, Metro, and HCI (Hyper-Converged Infrastructure) environments. With its advanced features and robust design, it meets the demanding requirements of modern network infrastructures.
The RX24F53 Switch offers two switching methods: Store and Forwarding and Cut Through. This flexibility allows it to adapt to different network traffic scenarios, ensuring efficient data transmission. Whether dealing with large data packets or real-time traffic, the switch can handle it effectively, minimizing delays and maximizing throughput.
Equipped with 24 x 40GE QSFP+ Ports, the switch provides high-speed connectivity for various network devices. The dual core ARM A53 CPU, along with 8GB Flash and 2GB Memory, ensures smooth operation and efficient handling of network tasks. Additionally, it features 1 RJ-45 Console port, 1 RJ-45 out-of-band management port, and 1 Type-A USB port, offering convenient management and maintenance options.
The switch supports multiple power supply types, including AC, DC, and HVDC, making it suitable for different power environments. With double power input and pluggable power supply modules, it enhances system reliability and ensures uninterrupted operation. It also comes with overcurrent and overvoltage protection, as well as a 4KV surge protection level, safeguarding the device and connected equipment from electrical hazards.
Featuring 4 pluggable fan modules with intelligent speed control, the switch maintains optimal operating temperature. The front-to-rear airflow design helps in efficient heat dissipation, ensuring the switch operates within the safe temperature range even under heavy loads. This extends the lifespan of the device and reduces the risk of downtime due to overheating.
With a switching capacity of 1.92 Tbps and a throughput of 1428.48 Mpps, the RX24F53 Switch delivers exceptional performance. The low latency of 700 ns ensures quick data transmission, which is crucial for time-sensitive applications. Its high MTBF (Mean Time Between Failures) of over 70080 hours (more than 8 years) reflects its reliability and durability, making it a cost-effective choice for long-term network deployments.
In data centers, the RX24F53 Switch serves as an ideal TOR (Top of Rack) access switch. It connects servers, storage devices, and other network equipment in the rack, providing high-speed and reliable connectivity. The high port density and performance capabilities allow it to handle the large volume of data traffic in data center environments, supporting virtualization and cloud computing applications.
For enterprise networks, the switch can be used for access or aggregation. It connects various end-user devices, such as computers, IP phones, and printers, providing seamless communication and data sharing. The advanced features and security capabilities of the switch help in maintaining a stable and secure enterprise network, ensuring efficient business operations.
In metro networks, the RX24F53 Switch plays a vital role in connecting different network nodes. It supports the transmission of large amounts of data over long distances, ensuring high-speed and reliable communication between cities and regions. The switch's robust design and ability to handle diverse traffic types make it suitable for metro network applications.
Hyper-Converged Infrastructure combines computing, storage, and networking into a single integrated system. The RX24F53 Switch is well-suited for HCI network access or aggregation, providing the necessary bandwidth and low latency to support the integrated infrastructure. It enables efficient data transfer between the different components of the HCI system, enhancing overall system performance.
