In the fast-evolving landscape of data centers and enterprise networks, where data volumes are doubling every two years and real-time processing demands are skyrocketing, Server Power Network Adapter Cards have become the backbone of modern IT infrastructure. These critical components bridge the gap between power management and network connectivity, ensuring seamless data flow, stable operation, and optimized energy usage across diverse environments. This article explores three innovative solutions—OCPSF10G-S, PSF400P, and PSF200P—each engineered to address specific infrastructure challenges with cutting-edge technology and SEO-optimized technical details.
| Quantity: | |
|---|---|
The PSF400P redefines versatility as a Server Power Network Adapter Card that merges a 400W 80 Plus Gold-certified power supply with enterprise-grade network capabilities. Unlike standalone power supplies, it integrates dual network ports to streamline infrastructure, reducing cable clutter and improving system reliability. Designed for 24/7 operation in servers, network-attached storage (NAS), and industrial control systems, its robust engineering ensures stable performance even in environments with temperature fluctuations and voltage variations.
Parameter | Value |
Power Output | 400W continuous (peak: 480W), 80 Plus Gold efficiency (115V: 87%@20%, 90%@50%, 87%@100%) |
Network Interface | 1x 10GBASE-T RJ45 port (CAT6a/CAT7 compatible), 1x SFP+ port (10Gbps) |
Input Voltage | 100-240V AC (auto-ranging), 50/60Hz, input current: 6A@100V, 3A@240V |
Safety Certifications | UL 60950-1, CE EN 60950-1, FCC Part 15 Class B, RoHS 2.0 compliant |
Dimensions | 150mm x 81.5mm x 40.5mm (1U rack-mountable, hot-swappable design) |
80 Plus Gold Efficiency: Achieves 90% efficiency at 50% load, cutting energy waste by 30% compared to non-certified power supplies and reducing annual operational costs by up to $150 per unit in high-usage environments.
Dual Network Ports: Combines 10GBASE-T (for copper cabling up to 100m) and SFP+ (for fiber/copper direct attach up to 10km) to support flexible network topologies.
Active PFC (Power Factor Correction): Maintains a power factor of >0.95 across all input voltages, reducing harmonic distortion and ensuring compliance with international grid standards (IEC 61000-3-2).
Redundant Cooling: Dual 40mm fans with PWM (Pulse Width Modulation) control adjust speed from 2000 RPM to 6000 RPM based on load, keeping noise levels below 45dB at 50% load.
Industrial-Grade Reliability: Meets MIL-STD-810H standards for shock (50G, 11ms) and vibration (10-2000Hz, 10G), making it suitable for factory floors and remote field deployments.
Enterprise Servers: Powers mission-critical database servers in banking and government sectors, where sudden power interruptions could result in millions in losses.
Edge Computing: Delivers consistent performance in remote locations such as oil rigs and rural telecom towers, where grid stability is unpredictable.
Industrial Automation: Integrates with PLCs (Programmable Logic Controllers) and robotic arms in automotive plants, supporting real-time machine-to-machine communication with sub-10ms latency.
